For Sale Anritsu LMR Site Master S412e Spectrum Network Analyzer. Only US$21,900. A highly versatile second generation handheld multifunction analyzer, designed for field technicians and engineers who install and maintain Land Mobile Radio (LMR) systems for public safety, utilities, and commercial.
Measurement Capabilities
The S412E consolidates multiple benchtop instruments into a single, ruggedized handheld platform weighing less than 7.6 lbs.
- Spectrum Analyzer: Operates from 9 kHz to 1.6 GHz (extendable up to 6 GHz via software options). Features excellent sensitivity, a Displayed Average Noise Level (DANL) of –152 dBm, and automated measurements like Occupied Bandwidth and Adjacent Channel Power.
- Vector Network Analyzer (VNA): Offers 2-port transmission and reflection measurements from 500 kHz to 1.6 GHz (extendable to 6 GHz). Used for detailed cable and antenna analysis, evaluating Return Loss, VSWR, Insertion Loss, and Distance-to-Fault (DTF) to pinpoint cable defects.
- Signal Generator: Includes an internal Vector Signal Generator spanning 500 kHz to 1.6 GHz. It yields adjustable power from 0 dBm to –130 dBm to test receiver sensitivity for both analog and digital radio systems. [1, 2, 3, 4]
- Power Meter: Features an internal power meter (9 kHz to 1.6 GHz) with support for external high-power sensors to verify up to 150-watt transmitter setups safely.
gloria jess –
This analyzer is very precise with minimal error. It’s definitely worth it for long-term use. The seller is very responsive.
