Up For Sale ALCATEL ADIXEN ASM 182 TD+ LEAK DETECTOR Good Condition and Ready To use, High performance dry helium leak detector designed for demanding industrial, semiconductor and quality control applications.
ALCATEL ADIXEN ASM 182 TD Specifications
The system stands out for its high sensitivity and its oil-free “dry” roughing system, making it ideal for cleanroom and clean-process environments.
| Technical Parameter | Specification / Value |
|---|---|
| Roughing/Backing Pump | Frictionless ACP dry multi-stage roots pump |
| Backing Pump Capacity | 25 m³/h (15 CFM) |
| Helium Pumping Speed | 4.4 l/s |
| Minimum Detectable Leak (Vacuum Mode) | 5 ⋅ 10⁻¹² mbar⋅l/s |
| Minimum Detectable Leak (Sniffing Mode) | 1 ⋅ 10⁻⁷ mbar⋅l/s |
| Inlet Flange Interface | KF40 |
| Power Requirements | Available in single-phase 100–115 V or 230 V at 50/60 Hz |
Features & Functionality
- 100% Oil-Free Design: Utilizing a frictionless compact multi-stage roots backing pump ensures zero risk of oil contamination in your testing environment or vacuum lines.
- Dual Vacuum Test Architecture: It uses automated gross leak contraflow and fine leak direct flow modes to offer reliable testing across extended pressure ranges.
- Rapid Cycle Times: The massive 15 CFM roughing capacity quickly evacuates large-volume test parts, minimizing production-line bottlenecks.
- Integrated Auto-Calibration: Features an internal temperature-compensated helium-calibrated leak standard to ensure accuracy over long operational cycles.
- Rugged, Accessible Enclosure: Designed with fold-out front and rear housing sides for easy, tool-free access during routine maintenance.
- Operator Enhancements: Features a distinct English-language voice synthesizer, combined digital/analog displays, and an external remote control for flexible monitoring.
