For sale Spectrum Analyzer 44 GHz Agilent E4446A , Only $12.000,00. Good condition and ready to use, come with 1 year warranty. That it remains a highly sought-after instrument in telecommunications, aerospace, defense, and R&D laboratories due to its premium performance characteristics and exceptional dynamic range.
Spectrum Analyzer 44 GHz Agilent E4446A Specifications
- Frequency Range: 3 Hz to 44 GHz (can expand up to 325 GHz using external mixers).
- Absolute Amplitude Accuracy: ±0.19 dB for highly precise level verification.
- Displayed Average Noise Level (DANL): -155 dBm for detecting weak signals.
- Phase Noise: -118 dBc/Hz at a 10 kHz offset.
- Analysis Bandwidth: 10 MHz standard, expandable up to 80 MHz with optional digitizers.
- Resolution Bandwidth (RBW): 1 Hz to 8 MHz in 10% steps.
- Dynamic Range: 81 dB W-CDMA ACLR.
