Hot Sale Fluke 5500A Multifunction Calibrator, only $11.200,00. A precision laboratory instrument designed to serve as a versatile standard for electrical calibration workloads. It serves as a highly accurate source for a wide variety of common test equipment, simulating electrical and thermal conditions for testing and verifying digital multimeters, thermometers, data loggers, and wattmeters.
Fluke 5500A Multifunction Calibrator Specifications
- Weight: 20 kg (44 lbs) without optional additions.
- Physical Dimensions: Height is 17.8 cm (7 inches), width is 43.2 cm (17 inches standard rack), and depth is 47.3 cm (18.6 inches).
- Line Power Requirements: Selectable options for 100V, 120V, 220V, or 240V at 47 Hz to 63 Hz, with a power draw of roughly 300 VA.
Technical Capabilities
- DC & AC Voltage: Sources DC voltage from 0 to ±1020V (best 1-year accuracy of ±50 ppm). Sources AC voltage up to 1020V with frequencies between 10 Hz and 500 kHz.
- DC & AC Current: Delivers DC current from 0 to ±11A and AC current up to 11A (10 Hz to 10 kHz).
- Resistance & Capacitance: Provides continuously variable resistance up to 330 MΩ and capacitance ranging from 0.33 nF to 1.1 mF.
- Temperature Simulation: Directly simulates 11 types of thermocouples (-250°C to +2316°C) and RTD temperature sensors.
- Power & Phase: Emits dual DC or AC outputs simultaneously to replicate power with precise phase control, allowing direct calibration of power quality instruments and wattmeters.
